Mini Rebar Locator

Mini R-Meter™
Economic System for Rebar Location

A rugged hand held field instrument for finding the location, depth and size of reinforcement rebar, post tension cable, copper and conduit in place.

Applications

• Rebar Locating Detection and Orientation
• Measurement of Concrete Cover
• Concrete Drilling and Sawing
• Repair and Rehabilitation
• Location of Prestressed Cables
• Contractors

Features & Benefits

• Eddy current design for greater accuracy.
• Single sensor for all depth ranges.
• Daylight visible display
• Locates up to 8″ (200mm)
• Economical

• Store Data for Later Upload via USB

Specifications

Operating temperature range: -5 C to 45 C (23 deg F to 113 F)

Bar Size Calibration: 3/8″ to 1-3/8″

Max. Detection Range: 10″ (No.11 Bar) 250 mm (36 mm Bar)

Power Source: 2 AA

Battery Life: 4 hours continuous operation

Software: Windows Compatible/ USB Required

HR-8000 and HR-8100 only:

Operating Weight: Less than 3.5 pounds (1.60 Kg)
