Silver corrosion

The apparatus, suitable for the execution of the test at 50°C, consists of a steel case containing a stainless steel bath with a four-hole cover for the test tubes and a manifold for connecting water to the condensers.

• Enamel finished benchtop steel case.
• Stainless steel inner bath with a four-hole cover for the test tubes.
• Manifold for connecting in parallel four condensers “cold finger” type.
• Electrical stirrer.
• Stainless steel heater.
• Electronic temperature control PID via a microprocessor controlled thermoregulator with built-in temperature display 0.1°C accuracy. The probe is a Pt100 RTD class 1/3 DIN: regulation accuracy ± 0.1°C.
• Safety devices that cut off the power supply and light a lamp on the control panel in case of overheating or lowering of the liquid level in the bath.
• Easy access control box on the right side of the apparatus containing all the electronic and electrical components: aluminium control panel with english written indications.
• English written user manual.
• For 220/50Hz connections. Power consumption 1200W.
• Dimensions (l x w x h): 600 x 400 x 900 approx. Weight 60 kg approx.
• CE marked.

IP0227-100          Four-place unit

IP0227-110          Six-place unit

IP0227-120          Eight-place unit

ACCESSORIES

IP0227-A00          ASTM comparative table

IP0227-A01          Strip vise for four strips

CAL001                PT100 simulator

CAL002                Officially certified PT100 simulator

CONSUMABLES

IP0227-C00         Amber-glass sample container

IP0227-C01         Amber-glass condenser

IP0227-C02         Silver strip support

IP0227-C03         Silver strip

IP0227-C04         Pack of 12 abrasive paper sheets, 240 grit

IP0227-C05         Pack of 12 abrasive paper sheets, 150 grit

IP0227-C06         Silicone carbide powder, 150 grit, 0.5 kg

TA012C-N00       ASTM 12C thermometer (-20°C/+102°C)
